CENTRIC
12199158

第三方数据CENTRIC : 12199158

Rotor
CENTRIC : 12199158

ABS Sensor Ring Included: No
Bolt Circle Diameter (IN): 5.512
Bolt Circle Diameter (MM): 140.000
Disc Mounting: Floating
Discard Thickness (IN): 1.024
Discard Thickness (MM): 26.000
Hat ID (IN): 6.701
Hat ID (MM): 170.200
Misc Holes: 2
Nominal Thickness (IN): 1.102
Nominal Thickness (MM): 28.000
OEM Vane Count: 56
Outside Diameter (IN): 12.626
Outside Diameter (MM): 320.700
Overall Height (IN): 1.811
Overall Height (MM): 46.000
Solid Or Vented Type Rotor: Vented
Surface Type: Smooth
Vane Style: Straight

适用车型

MITSUBISHI (1)
