CENTRIC
12335001

第三方数据CENTRIC : 12335001

Drum
CENTRIC : 12335001

Bolt Circle Diameter (IN): 3.937
Bolt Circle Diameter (MM): 100.000
Bolt Hole Quantity: 4
Friction Surface Width (IN): 1.772
Friction Surface Width (MM): 45.000
Height (IN): 2.524
Height (MM): 64.100
Hub Hole / Register (IN): 2.402
Hub Hole / Register (MM): 61.000
Maximum Brake Diameter (Discard) (IN): 8.049
Maximum Brake Diameter (Discard) (MM): 204.450
Misc Holes: 2
Mounting Hole Diameter (IN): 0.531
Mounting Hole Diameter (MM): 13.500
Mounting Type: Floating
Nominal Drum Diameter (IN): 7.992
Nominal Drum Diameter (MM): 203.000
Outer Cooling Fins: Yes
Outside Diameter (IN): 9.331
Outside Diameter (MM): 237.000

适用车型

SMART (3)
