DURAGO
BR31318

第三方数据DURAGO : BR31318

Rotor
DURAGO : BR31318

Abs Tone Ring Included: No
Center Hole Diameter (IN): 2.52
Center Hole Diameter (MM): 64.1
Construction: Full Cast
Conventional Or Drum-In-Hat Type Rotor: Drum-in-Hat
Cross Drilled: No
Directional or Non-Directional Brake Surface: Non-Directional
Discard Thickness (IN): 0.37
Discard Thickness (MM): 9.5
Material: Cast Iron
Mounting Bolt Hole Circle Diameter (IN): 4.5
Mounting Bolt Hole Circle Diameter (MM): 114.3
Mounting Bolt Hole Diameter (IN): 0.51
Mounting Bolt Hole Diameter (MM): 12.9
Mounting Bolt Hole Quantity: 5
Nominal Thickness (IN): 0.44
Nominal Thickness (MM): 11.1
Outside Diameter (IN): 12.32
Outside Diameter (MM): 313
Overall Height (IN): 2.2
Overall Height (MM): 56
Rust Resistant Coating: No
Slotted: No
Solid Or Vented Type Rotor: Solid

适用车型

HONDA (1)

ACURA (1)

OE号码

品牌	号码
OE	AX3131*

品牌	号码
OE	31318G:*

品牌	号码
OE	12605*
