CENTRIC
12199133

第三方数据CENTRIC : 12199133

Rotor
CENTRIC : 12199133

ABS Sensor Ring Included: No
Bolt Circle Diameter (IN): 4.252
Bolt Circle Diameter (MM): 108.000
Disc Mounting: Floating
Discard Thickness (IN): 1.102
Discard Thickness (MM): 28.000
Hat ID (IN): 5.232
Hat ID (MM): 132.900
Misc Holes: 3
Nominal Thickness (IN): 1.181
Nominal Thickness (MM): 30.000
Outside Diameter (IN): 13.386
Outside Diameter (MM): 340.000
Overall Height (IN): 1.358
Overall Height (MM): 34.500
Solid Or Vented Type Rotor: Vented
Surface Type: Smooth

适用车型

PEUGEOT (1)
