Rotor
BOSCH : 38011004

Bearings Included: No
Brake Surface Finish: Solid
Center Bore Diameter: 69 mm
Construction: Vented
Conventional Or Drum-In-Hat Type Rotor: Conventional
Directional or Non-Directional Brake Surface: Directional
Disc Finish: Geomet
Discard Thickness: 22.4 MM
Mounting Bolt Hole Circle Diameter: 114.3 mm
Mounting Bolt Hole Quantity: 4
Nominal Thickness: 24 mm
Outside Diameter: 255.8 MM
Overall Height: 45.5 mm
Product Height: 1.791339 in
Rotor Without Hub Assembly: Yes
Rust Resistant Coating: Yes
Thickness (Disc Brake Rotor): 24 mm

适用车型

MITSUBISHI (1)

参考号

厂商	号码
AUTOZONE/RAYBESTOS	96517*

OE号码

品牌	号码
OE	MR38972*
