第三方数据BOSCH : 25010659

Rotor
BOSCH : 25010659

Bearings Included: No
Brake Surface Finish: Solid
Center Bore Diameter: 70.7 MM
Construction: Vented
Conventional Or Drum-In-Hat Type Rotor: Drum-in-Hat
Directional or Non-Directional Brake Surface: Directional
Disc Finish: Geomet
Discard Thickness: 24 mm
Mounting Bolt Hole Circle Diameter: 115 mm
Mounting Bolt Hole Quantity: 6
Nominal Thickness: 26.2 MM
Outside Diameter: 320 mm
Overall Height: 48.2 mm
Product Height: 1.897638 in
Rotor Without Hub Assembly: Yes
Rust Resistant Coating: Yes
Thickness (Disc Brake Rotor): 26.2 MM

适用车型

CADILLAC (1)

参考号

厂商	号码
DFC	1311-0551-0*

OE号码

品牌	号码
OE	1930381*
