BOSCH
20011482

第三方数据BOSCH : 20011482

Rotor
BOSCH : 20011482

Bearings Included: No
Brake Surface Finish: Solid
Center Bore Diameter: 72 mm
Construction: Vented
Conventional Or Drum-In-Hat Type Rotor: Conventional
Directional or Non-Directional Brake Surface: Directional
Disc Finish: Geomet
Discard Thickness: 8 mm
Mounting Bolt Hole Circle Diameter: 114.3 mm
Mounting Bolt Hole Quantity: 5
Nominal Thickness: 10 mm
Outside Diameter: 279.6 MM
Overall Height: 40.5 mm
Product Height: 1.594488 in
Rotor Without Hub Assembly: Yes
Rust Resistant Coating: Yes
Thickness (Disc Brake Rotor): 10 mm

适用车型

MAZDA (1)

OE号码

品牌	号码
OE	GK2Y26251*
