第三方数据AUTO EXTRA : AX54073

Rotor
AUTO EXTRA : AX54073

Abs Tone Ring Included: No
Center Hole Diameter (IN): 5
Center Hole Diameter (MM): 127
Construction: Full Cast
Conventional Or Drum-In-Hat Type Rotor: Drum-in-Hat
Cross Drilled: No
Directional or Non-Directional Brake Surface: Non-Directional
Discard Thickness (IN): 1.1
Discard Thickness (MM): 28
Material: Cast Iron
Mounting Bolt Hole Circle Diameter (IN): 6.5
Mounting Bolt Hole Circle Diameter (MM): 165.1
Mounting Bolt Hole Diameter (IN): 0.65
Mounting Bolt Hole Diameter (MM): 16.5
Mounting Bolt Hole Quantity: 8
Nominal Thickness (IN): 1.18
Nominal Thickness (MM): 30
Outside Diameter (IN): 12.83
Outside Diameter (MM): 326
Overall Height (IN): 3.87
Overall Height (MM): 98.4
Rust Resistant Coating: No
Slotted: No
Solid Or Vented Type Rotor: Vented

适用车型

FORD (3)

E-150 (2)

E-250 (2)

E-350 (3)

OE号码

品牌	号码
OE	AX54073:*
