ASTRA
18A82613

第三方数据ASTRA : 18A82613

Rotor
ASTRA : 18A82613

Abs Tone Ring Included: No
Bearings Included: No
Bolt Circle Diameter (IN): 4.5
Bolt Circle Diameter (MM): 114.3
Center Hole Diameter (IN): 2.799
Center Hole Diameter (MM): 71.1
Construction: Full Cast
Conventional Or Drum-In-Hat Type Rotor: Conventional
Directional or Non-Directional Brake Surface: Non-Directional
Disc Finish: Coated
Discard Thickness (IN): 0.413
Discard Thickness (MM): 10.5
Height (IN): 1.06
Height (MM): 27
Inside Diameter (IN): 8.843
Inside Diameter (MM): 224.6
Material: Cast Iron
Mounting Bolt Hole Circle Diameter (IN): 4.5
Mounting Bolt Hole Circle Diameter (MM): 114.3
Mounting Bolt Hole Diameter (IN): 0.626
Mounting Bolt Hole Diameter (MM): 15.9
Nominal Thickness (IN): 0.472
Nominal Thickness (MM): 12
Outside Diameter (IN): 12.591
Outside Diameter (MM): 319.8
Overall Height (IN): 1.063
Overall Height (MM): 27
Solid Or Vented Type Rotor: Solid
Surface Type: Smooth

适用车型

FORD (1)

OE号码

品牌	号码
OE	1942509*
