GM GENUINE
84743114

第三方数据GM GENUINE : 84743114

Radiator
GM GENUINE : 84743114

Coolant Level Indicator Port: No
Core Height (IN): 12.42
Core Height (MM): 315.56
Core Material: Aluminum
Core Row Quantity: 1
Core Thickness (IN): 0.89
Core Thickness (MM): 22.51
Core Width (IN): 22.44
Core Width (MM): 570.02
Down Flow Or Cross Flow Type: Cross Flow
Engine Oil Cooler Included: No
Frame Included: No
Inlet Diameter (IN): 0.64
Inlet Diameter (MM): 16.15
Inlet Header Length (IN): 13.07
Inlet Header Length (MM): 332
Inlet Header Width (IN): 1.02
Inlet Header Width (MM): 26
Inlet Location: 0.64
Internal Engine Oil Cooler: No
Internal Transmission Oil Cooler: No
Mounting Hardware Included: No
Mounting Type: Bolted
Outlet Diameter (IN): 0.63
Outlet Diameter (MM): 16.15
Outlet Header Length (IN): 13.07
Outlet Header Length (MM): 332
Outlet Header Width (IN): 1.02
Outlet Header Width (MM): 26
Outlet Location: Buttom Left
Radiator Cap Included: No
Tank Material: Aluminum
Thermostat Included: No
Transmission Oil Cooler Included: No

适用车型

CADILLAC (2)

CT5 (2)

CT4 (1)
