REIN
PSH0573

第三方数据REIN : PSH0573

Power Steering Pressure Hose
REIN : PSH0573

Banjo Bolt Included: No
Clamps Included: No
Crush Washers Included: Yes
End 1 Inside Diameter (MM): 16.0000
End 1 Outside Diameter (MM): 24.0000
End 2 Inside Diameter (MM): 16.0000
End 2 Outside Diameter (MM): 24.0000
Fitting Seals Included: Not Required
Heat Shield Included: Not Required
High Pressure End 1 Type: Banjo
High Pressure End 2 Type: Banjo
High Pressure Hose Burst Pressure PSI: 8700
High Pressure Hose Material: NBRNBRCR
High Pressure Hose Operating Pressure PSI: 1700
Hose Crimp End Finish: Zinc Alloy
Hose Crimp End Material: Carbon Steel
Low Pressure End 1 Inside Diameter (MM): 8.0000
Low Pressure End 1 Outside Diameter (MM): 12.0000
Low Pressure End 1 Type: Tube
Low Pressure End 2 Inside Diameter (MM): 8.0000
Low Pressure End 2 Outside Diameter (MM): 12.0000
Low Pressure End 2 Type: Tube
Low Pressure Hose Burst Pressure PSI: 1000
Low Pressure Hose Material: NBRCR
Low Pressure Hose Operating Pressure PSI: 250.0000
Mounting Brackets Included: Yes
Pressure Switch Port Included: Not Required
Protective Sleeve Included: Not Required
Tubing Finish: Zinc Alloy
Tubing Material: Carbon Steel

适用车型

MAZDA (1)

OE号码

品牌	号码
OE	BBY13241*

品牌	号码
OE	BBY132410*
