Piston Ring
HASTINGS MANUFACTURING : 2C4781

1st Oil Groove: 2.50 mm
1st Oil Ring Material: Steel Rail / Stainless Expander
1st Oil Ring Surface Treatment: Chrome Rail
2nd Groove: 1.20 mm
2nd Ring Material: Grey Iron
2nd Ring Surface Treatment: Phosphate
Cylinder Quantity: 6
Engine Bore (MM): 93.00 MM
Engine Bore (in.): 3.661 in.
Top Groove: 1.20 mm
Top Ring Material: Steel
Top Ring Surface Treatment: Chrome

适用车型

ISUZU (2)

NISSAN (1)

ARMADA (1)

5.6L V8 (9)

2007	Full Set; Chrome Top Ring; Top Groove: 1.20 mm; 2nd Groove: 1.20 mm; 1st Oil Groove: 2.50 mm; For 2 Ring Piston 2C4781, 2C4781010, 2C4781020, 2C4781030, 2C4781040

2008	Full Set; Chrome Top Ring; Top Groove: 1.20 mm; 2nd Groove: 1.20 mm; 1st Oil Groove: 2.50 mm; For 2 Ring Piston 2C4781, 2C4781010, 2C4781020, 2C4781030, 2C4781040

2009	Full Set; Chrome Top Ring; Top Groove: 1.20 mm; 2nd Groove: 1.20 mm; 1st Oil Groove: 2.50 mm; For 2 Ring Piston 2C4781, 2C4781010, 2C4781020, 2C4781030, 2C4781040

2010	Full Set; Chrome Top Ring; Top Groove: 1.20 mm; 2nd Groove: 1.20 mm; 1st Oil Groove: 2.50 mm; For 2 Ring Piston 2C4781, 2C4781010, 2C4781020, 2C4781030, 2C4781040

2011	Full Set; Chrome Top Ring; Top Groove: 1.20 mm; 2nd Groove: 1.20 mm; 1st Oil Groove: 2.50 mm; For 2 Ring Piston 2C4781, 2C4781010, 2C4781020, 2C4781030, 2C4781040

2012	Full Set; Chrome Top Ring; Top Groove: 1.20 mm; 2nd Groove: 1.20 mm; 1st Oil Groove: 2.50 mm; For 2 Ring Piston Platinum; SL Model; SV Model 2C4781, 2C4781010, 2C4781020, 2C4781030, 2C4781040

2013	Full Set; Chrome Top Ring; Top Groove: 1.20 mm; 2nd Groove: 1.20 mm; 1st Oil Groove: 2.50 mm; For 2 Ring Piston Platinum; SL Model; SV Model 2C4781, 2C4781010, 2C4781020, 2C4781030, 2C4781040

2014	Full Set; Chrome Top Ring; Top Groove: 1.20 mm; 2nd Groove: 1.20 mm; 1st Oil Groove: 2.50 mm; For 2 Ring Piston Platinum; SL Model; SV Model 2C4781, 2C4781010, 2C4781020, 2C4781030, 2C4781040

2015	Full Set; Chrome Top Ring; Top Groove: 1.20 mm; 2nd Groove: 1.20 mm; 1st Oil Groove: 2.50 mm; For 2 Ring Piston Platinum; SL Model; SV Model 2C4781, 2C4781010, 2C4781020, 2C4781030, 2C4781040

BUICK (1)

CHEVROLET (2)

HUMMER (1)

INFINITI (1)

GMC (2)

OE号码

品牌	号码
OE	2C478101*
OE	2C478102*

品牌	号码
OE	2C478103*

品牌	号码
OE	2C478104*
