CENTRIC
13051030

第三方数据CENTRIC : 13051030

Master Cylinder
CENTRIC : 13051030

Bleeder Hoses Included: No
Brake Booster Included: No
Master Cylinder Bore Diameter (IN): 1.000
Master Cylinder Bore Diameter (MM): 25.400
Master Cylinder Cap Included: Yes
Master Cylinder Material: Aluminum
Mounting Bracket Included: No
Mounting Hardware Included: No
Mounting Hole Quantity: 2
Port Quantity: 3
Primary Outlet Flare Type: Bubble
Primary Outlet Thread Diameter (MM): 12.000
Primary Outlet Thread Pitch (MM): 1.00
Push Rod: Length / Depth (IN): 1.01
Pushrod Included: No
Reservoir Included: Yes
Reservoir Material: Plastic
Reservoir Type: Single
Secondary Outlet Flare Type: Bubble
Secondary Outlet Thread Diameter (MM): 12.000
Secondary Outlet Thread Pitch (MM): 1.00

适用车型

KIA (1)

参考号

厂商	号码
ADVANCE/CARQUEST PREMIUM AC	MCA63039*
ADVANCE/CARQUEST WEAREVER	MCA63039*
ADVANCE/CARQUEST WEAREVER BRAKES	MCA63039*
ADVANCE/CARQUEST WEAREVER MASTER CYL	11-323*
ADVANCE/CARQUEST WEAREVER MASTER CYL	48644*
AUTOPART INTERNATIONAL	9966*
AUTOPART INTERNATIONAL	1475-9966*

厂商	号码
BRAKEBEST	11-323*
BRAKEBEST	MC63039*
CARQUEST WEAREVER MASTER CYLINDERS	11-323*
CARQUEST/ WEAREVER BRAKES	MCA63039*
DFC	355-2106*
DORMAN	M63039*
DORMAN - FIRST STOP	M63039*

厂商	号码
MANDO	17A112*
PARTS MASTER/DORMAN	MC63039*
PARTS PLUS	2302-5103*
PRONTO/DORMAN	M63039*
TRU TORQUE	M63039*
WAGNER BRAKE	MC14242*
WAGNER BRAKE	F14242*

OE号码

品牌	号码
OEM PART NUMBER	585103F00*
