GM GENUINE
11548720

第三方数据GM GENUINE : 11548720

Harmonic Balancer Bolt
GM GENUINE : 11548720

Bolt Grade: 10.9
Finish: Zinc
Head Diameter (IN): 2.05
Head Diameter (MM): 52
Head Drive Type: Hex
Head Shape: Round
Head Tool Size: 24
Material: Steel
Overall Length (IN): 6.95
Overall Length (MM): 176.5
Partially Threaded: Yes
SAE or Metric: Metric
Self Drilling: No
Self Tapping: No
Shank Diameter (MM): 16
Shank Length (IN): 2.48
Shank Length (mm): 63
Thread Diameter (MM): 16
Thread Direction: Clockwise
Thread Length (MM): 92.5
Thread Pitch (mm): 2
Thread Type: Coarse
Threads Per Inch: 12.7
Type: Flange
Under Head Length (IN): 6.24
Under Head Length (MM): 158.5
Washer Attached: No

适用车型

CHEVROLET (1)
