第三方数据FVP : 12399039

Drum
FVP : 12399039

Bolt Circle Diameter in: 4.250
Bolt Circle Diameter mm: 107.950
Bolt Hole Quantity: 4
Disc Mounting: Floating
Friction Surface Width in: 1.937
Friction Surface Width mm: 49.200
Friction Surface mm: 49.2
Height IN: 2.772
Height MM: 70.400
Hub Hole / Register in: 2.500
Hub Hole / Register mm: 63.500
Max Diameter mm: 230.2
Maximum Brake Diameter (Discard) (IN): 9.060
Maximum Brake Diameter (Discard) (MM): 230.100
Mounting Hole Diameter (IN): 0.551
Mounting Hole Diameter (MM): 14.000
Mounting Type: Floating
Nominal Diameter mm: 228.7
Nominal Drum Diameter (IN): 9.000
Nominal Drum Diameter (MM): 228.600
Number of Holes/Studs: 4
Outer Diameter MM: 273.0
Outside Diameter (IN): 10.748
Outside Diameter (MM): 273.000
Plain / Finned: P
Stud/Bolt Circle mm: 108.0
Stud/Bolt Hole Dia. mm: 14.0

适用车型

FORD (1)

OE号码

品牌	号码
OE	123-9903*
