FVP
12399021

第三方数据FVP : 12399021

Drum
FVP : 12399021

Bolt Circle Diameter in: 5.500
Bolt Circle Diameter mm: 139.700
Bolt Hole Quantity: 6
Disc Mounting: Floating
Friction Surface Width in: 2.870
Friction Surface Width mm: 72.900
Friction Surface mm: 72.90
Height IN: 3.594
Height MM: 91.300
Hub Hole / Register in: 3.701
Hub Hole / Register mm: 94.00
Max Diameter mm: 297.00
Maximum Brake Diameter (Discard) (IN): 11.690
Maximum Brake Diameter (Discard) (MM): 297.000
Mounting Hole Diameter (IN): 0.484
Mounting Hole Diameter (MM): 12.300
Mounting Type: Floating
Nominal Diameter mm: 294.80
Nominal Drum Diameter (IN): 11.600
Nominal Drum Diameter (MM): 294.700
Number of Holes/Studs: 6
Outer Cooling Fins: No
Outer Diameter MM: 343.00
Outside Diameter (IN): 13.504
Outside Diameter (MM): 343.000
Stud/Bolt Circle mm: 139.80
Stud/Bolt Hole Dia. mm: 12.3

适用车型

MITSUBISHI (2)

L200 (3)

MONTERO SPORT (2)
