Drum
CENTRIC : 12399038

Bolt Circle Diameter (IN): 3.858
Bolt Circle Diameter (MM): 98.000
Bolt Hole Quantity: 5
Friction Surface Width (IN): 1.787
Friction Surface Width (MM): 45.400
Height (IN): 2.406
Height (MM): 61.100
Hub Hole / Register (IN): 2.323
Hub Hole / Register (MM): 59.000
Maximum Brake Diameter (Discard) (IN): 9.055
Maximum Brake Diameter (Discard) (MM): 230.000
Misc Holes: 3
Mounting Hole Diameter (IN): 0.520
Mounting Hole Diameter (MM): 13.200
Mounting Type: Floating
Nominal Drum Diameter (IN): 8.976
Nominal Drum Diameter (MM): 228.000
Outside Diameter (IN): 10.579
Outside Diameter (MM): 268.700

适用车型

DODGE (1)
