CENTRIC
12376008

第三方数据CENTRIC : 12376008

Drum
CENTRIC : 12376008

Bolt Circle Diameter (IN): 8.750
Bolt Circle Diameter (MM): 222.250
Bolt Hole Quantity: 6
Friction Surface Width (IN): 6.449
Friction Surface Width (MM): 163.800
Height (IN): 8.661
Height (MM): 220.000
Hub Hole / Register (IN): 6.770
Hub Hole / Register (MM): 171.958
Maximum Brake Diameter (Discard) (IN): 14.646
Maximum Brake Diameter (Discard) (MM): 372.000
Mounting Hole Diameter (IN): 0.890
Mounting Hole Diameter (MM): 22.600
Mounting Type: Floating
Nominal Drum Diameter (IN): 14.290
Nominal Drum Diameter (MM): 363.000
Outer Cooling Fins: No
Outside Diameter (IN): 17.937
Outside Diameter (MM): 455.600

适用车型

ISUZU (1)
