CENTRIC
12376007

第三方数据CENTRIC : 12376007

Drum
CENTRIC : 12376007

Bolt Circle Diameter (IN): 8.750
Bolt Circle Diameter (MM): 222.250
Bolt Hole Quantity: 6
Friction Surface Width (IN): 5.354
Friction Surface Width (MM): 136.000
Height (IN): 7.776
Height (MM): 197.500
Hub Hole / Register (IN): 6.770
Hub Hole / Register (MM): 171.958
Maximum Brake Diameter (Discard) (IN): 12.657
Maximum Brake Diameter (Discard) (MM): 321.500
Misc Holes: 4
Mounting Hole Diameter (IN): 0.886
Mounting Hole Diameter (MM): 22.500
Mounting Type: Floating
Nominal Drum Diameter (IN): 12.598
Nominal Drum Diameter (MM): 320.000
Outer Cooling Fins: No
Outside Diameter (IN): 14.803
Outside Diameter (MM): 376.000

适用车型

ISUZU (1)
