CENTRIC
12346025

第三方数据CENTRIC : 12346025

Drum
CENTRIC : 12346025

Bolt Circle Diameter (IN): 3.937
Bolt Circle Diameter (MM): 100.000
Bolt Hole Quantity: 4
Friction Surface Width (IN): 1.429
Friction Surface Width (MM): 36.300
Height (IN): 2.260
Height (MM): 57.400
Hub Hole / Register (IN): 2.524
Hub Hole / Register (MM): 64.100
Maximum Brake Diameter (Discard) (IN): 8.071
Maximum Brake Diameter (Discard) (MM): 205.000
Misc Holes: 2
Mounting Hole Diameter (IN): 0.500
Mounting Hole Diameter (MM): 12.700
Mounting Type: Floating
Nominal Drum Diameter (IN): 7.984
Nominal Drum Diameter (MM): 202.800
Outer Cooling Fins: No
Outside Diameter (IN): 9.461
Outside Diameter (MM): 240.300

适用车型

MITSUBISHI (1)
