CENTRIC
12344022

第三方数据CENTRIC : 12344022

Drum
CENTRIC : 12344022

Bolt Circle Diameter (IN): 5.500
Bolt Circle Diameter (MM): 139.700
Bolt Hole Quantity: 6
Friction Surface Width (IN): 2.595
Friction Surface Width (MM): 65.920
Height (IN): 3.268
Height (MM): 83.000
Hub Hole / Register (IN): 4.173
Hub Hole / Register (MM): 106.000
Maximum Brake Diameter (Discard) (IN): 11.693
Maximum Brake Diameter (Discard) (MM): 297.000
Misc Holes: 8
Mounting Hole Diameter (IN): 0.571
Mounting Hole Diameter (MM): 14.500
Mounting Type: Floating
Nominal Drum Diameter (IN): 11.614
Nominal Drum Diameter (MM): 295.000
Outer Cooling Fins: No
Outside Diameter (IN): 13.484
Outside Diameter (MM): 342.500

适用车型

TOYOTA (2)

OE号码

品牌	号码
OE	123.4402*
