NUGEON
97S09332A

第三方数据NUGEON : 97S09332A

Caliper
NUGEON : 97S09332A

Anti-Squeal Shims Included: No
Bleeder Screw Cap Included: No
Bleeder Screw Included: Yes
Bleeder Screw Thread (MM): M10-1.0 x 28
Bleeder Thread Size: M10-1.0
Bracket Cast Numbers: N/R
Bracket Included: No
Bracket Mounting Bolts Included: No
Caliper And Pad Hardware Included: Yes
Caliper Casting Material: Aluminum
Caliper Color: Silver
Caliper Finish: Powder coat
Dust Boots Included: Yes
Hardware Included: Yes
Inlet Fitting Type: Line
Inlet Port Thread Size (MM): M10-1.0
Inlet Thread Size: M10-1.0
New Or Remanufactured: Remanufactured
Pads Included: No
Piston 1 Outside Diameter (in): 1.102
Piston 1 Outside Diameter (mm): 28
Piston 2 Outside Diameter (in): 1.181
Piston 2 Outside Diameter (mm): 30
Piston Material: Aluminum
Piston Quantity: 4
Wear Sensors Included: No

适用车型

VOLVO (2)

OE号码

品牌	号码
OE	22S09332*
