Caliper
CENTRIC : 14151038

Abutment Clips Included: Yes
Axle Leading/Trailing: Leading
Bleeder Install Thread Count (IN): 4.5
Bleeder Screw Included: Yes
Bleeder Thread Diameter (MM): 10.000
Bracket Required: Yes
Caliper Casting Material: Cast Iron
Caliper Color: Gray
Caliper Manufacturer: Mando
Caliper Type: Floating
Casting Number: PSPE57; HH3; HM1
Finish: Rust Preventative
Inlet Fitting Type: Banjo
Inlet Thread Diameter (MM): 10.000
Mount Spread - Center to Center: 128.0mm
Mount Thread Size (MM): M12-1.25
Mounting Bracket Included: Yes
Mounting Hardware Included: No
New or Ramanufactured: Remanufactured
Pad Wear Sensor Included: No
Pads Included: No
Piston Diameter (IN): 2.244
Piston Diameter (mm): 57.000
Piston Material: Steel
Piston Quantity: 1
Rust Preventative Coating: Yes

适用车型

HYUNDAI (1)

参考号

厂商	号码
BRAKEBEST CALIPERS	141.5103*
CASTING NUMBERS	P8PE5*

厂商	号码
NAPA	242-815*

厂商	号码
PROMECANIX	10-03703-*

OE号码

品牌	号码
OE	141.5103*

品牌	号码
OEM PART NUMBER	58110G310*

品牌	号码
OEM PART NUMBER	58180G3A1*
