14150524

第三方数据CENTRIC : 14150524

Caliper
CENTRIC : 14150524

Abutment Clips Included: Yes
Axle Leading/Trailing: Trailing
Bleeder Install Thread Count (IN): 4.5
Bleeder Screw Included: Yes
Bleeder Thread Diameter (MM): 10.000
Bracket Required: Yes
Caliper Casting Material: Cast Iron
Caliper Color: Gray
Caliper Manufacturer: Mando
Caliper Type: Floating
Casting Number: BC140276
Finish: Rust Preventative
Inlet Fitting Type: Banjo
Inlet Thread Diameter (MM): 10.000
Mount Spread - Center to Center: 100.0mm
Mount Thread Size (MM): M12-1.25
Mounting Bracket Included: Yes
Mounting Hardware Included: No
New or Ramanufactured: Remanufactured
Pad Wear Sensor Included: No
Pads Included: No
Piston Diameter (IN): 1.496
Piston Diameter (mm): 38.000
Piston Material: Steel
Piston Quantity: 1
Rust Preventative Coating: Yes

适用车型

KIA (1)

参考号

厂商	号码
BRAKEBEST CALIPERS	141.5052*
CASTING NUMBERS	BC14027*

厂商	号码
CASTING NUMBERS	BC41226*

厂商	号码
NAPA	242-816*

OE号码

品牌	号码
OEM PART NUMBER	58210F650*
OEM PART NUMBER	58210G850*

品牌	号码
OEM PART NUMBER	58310F6A5*

品牌	号码
OEM PART NUMBER	58310G8A5*
