CENTRIC
14146104

第三方数据CENTRIC : 14146104

Caliper
CENTRIC : 14146104

Abutment Clips Included: Yes
Axle Leading/Trailing: Leading
Bleeder Install Thread Count (IN): 5.5
Bleeder Screw Included: Yes
Bleeder Thread Diameter (MM): 7.000
Bracket Required: Yes
Caliper Casting Material: Cast Iron
Caliper Color: Gray
Caliper Manufacturer: Akebono
Caliper Type: Floating
Casting Number: 5108
Finish: Rust Preventative
Inlet Fitting Type: Banjo
Inlet Thread Diameter (MM): 10.000
Mount Spread - Center to Center: 128.0mm
Mount Thread Size (MM): M12-1.25
Mounting Bracket Included: Yes
Mounting Hardware Included: No
New or Ramanufactured: Remanufactured
Pad Wear Sensor Included: No
Pads Included: No
Piston Diameter (IN): 2.008
Piston Diameter (mm): 51.000
Piston Material: Steel
Piston Quantity: 1
Rust Preventative Coating: Yes

适用车型

MITSUBISHI (1)

参考号

厂商	号码
CASTING NUMBERS	510*

厂商	号码
CASTING NUMBERS	512*

OE号码

品牌	号码
OEM PART NUMBER	4605B00*
